Alignment and Ride Height
See also the Factory Setup Guide for a printable version of the factory alignment, tire pressures, ride height, and more.
Baseline Setup
Section titled “Baseline Setup”The factory RAW baseline PDF is linked in the Factory Setup Guide.
| Parameter | Front | Rear | Notes |
|---|---|---|---|
| Camber | -1.2° (in) | -0.8° (in) | — |
| Toe | 0.5mm out | 0.25mm in | — |
| Spring Rate | 700 lbs/in (Red) | 800 lbs/in (Blue) | — |
| ARB | Soft | Medium | Soft: Flush w/ End, Med: 25mm, Hard: 50mm |
| Shock Compression | 2 sweeps from closed | 2 sweeps from closed | — |
| Shock Rebound | 3 sweeps from closed | 3 sweeps from closed | — |
| Shock Preload | 1 turn | 2 turns | 25mm per turn |
| Shock Nitrogen Pressure | 300 PSI | 300 PSI | Check each session |
| Ride Height (frame-to-floor) | 476mm | 454mm | 22mm rake baseline |
| Splitter AOA | 1° angle of attack | — | — |
| Wing Setting | — | 1 of 6 | Lower number = smaller AOA |
| Tire Pressure | 19 PSI cold / 22 PSI hot | 19 PSI cold / 22 PSI hot | — |
| Corner Weights (w/ driver) | - | — | varies: 44–48% front |
| Brake Bias | 58% | 42% | Tune forward as needed |
Fuel Pressure (at idle): 45 PSI
Ride Height Reference
Section titled “Ride Height Reference”Baseline is Front 476mm frame-to-floor / Rear 454mm frame-to-floor / 22mm rake.
Each 1mm of rake difference equals approximately 0.17° of pitch angle. The 22mm baseline rake equals approximately 3.7° total pitch.
Steering slop
Section titled “Steering slop”Play at the wheel is a known characteristic, and how much you have depends on how old your car is. Later cars are noticeably better, because they ship with a steering rack we now design and build in-house rather than sourcing.
If the slop in your car is getting worse rather than simply being there, that is a different problem and worth inspecting. A rack that has always felt slightly vague on an early car is the known behaviour.
Talk to your dealer about what is available for your chassis before you start replacing parts on your own diagnosis.
